Bayesian Optimisation

Nam-Anh Tran

Motivations

Consider a “well behaved” function \(f:\mathfrak{X} \to \mathbb{R}\), where \(\mathfrak X \subseteq \mathbb{R}^d\) is a bounded domain.

\[ x_M = \arg\min_{x \in \mathfrak X} f(x) \]

How to optimize \(f\) if:

• \(f\) is explicitly unknown and multimodal.
• Evaluations of \(f\) are expensive.

Expensive functions

Parameter tuning in ML algorithms

• Number of layers/units per layer.
• Weight penalties
• Learning rates, etc.

Expensive functions

Design of experiments: gene optimization

• Optimize genes [tweak the DNA sequence] (ATTGGTUGA…) to best enable the cell-factory to operate most efficiently (yeast to produce insulin or vaccines.)

These tweaks might include changing codons, promoter strength, regulatory elements, etc.

Expensive functions

Dose finding in drug development

Find the MTD which maximizes the efficacy but the toxicity is still under control.

• Pre-specified models must hold monotonicity.
• However, it may not hold and we do not have information before observing data.
• We even don’t have enough data to assess this assumption.

What to do?

• Option 1: Use previous knowledge to select the parameters at hand. Perhaps not very scientific but still in use.
• Option 2: Grid search. It is very computationally expensive and does not reuse knowledge from previous runs.
• Option 3: Pure Random search. It is better than grid search in various senses but still expensive.

Can we do better?

• Find the optimum of function \(f\) in the interval \([0,1]\).
• \(f\) is continuous.

• Where is the minimum of \(f\)?

• There is not enough information to know the minimum point; more evaluations are required.

• Where should we take the next evaluation?

• This implies a level of uncertainty regarding the function we are minimizing.

• Is the current observed minimizer true?
• If not, where should we evaluate next?
• How to account for these two features in the policy function?

General ideas: Surrogate modelling

• Use a surrogate model of \(f\) to carry out the optimization.
• Define a utility function to collect new data points satisfying some optimality: Optimization \(\to\) decision.
• Study decision problems as inference using the surrogate model. A probabilistic model can calibrate both first-ordered and second-ordered uncertainty.

“I want to find the minimum of an expensive black-box function (like training accuracy), but I can only evaluate it a few times.”

Surrogate model: Gaussian process

Infinite-dimensional probability density, such that each linear finite-dimensional restriction is multivariate Gaussian.

• Model \(f(x) \sim GP(\mu(x), K(x,x'))\) is determined by the mean function and covariance function.
• Allows tractable Bayesian modelling of functions without specifying a particular finite basis (i.e. \(\sum_{i=1}^Mw_i\phi_i(x)\)) that might not be flexible enough to fit complex functions.
• Closed-form predictive distribution, i.e. conditional distribution of new data conditional on observed data.

Surrogate model: Gaussian process

\[ p(f, \boldsymbol y) = GP\bigg( \begin{bmatrix}f \\ \boldsymbol y \end{bmatrix}; \begin{bmatrix}\mu \\ \boldsymbol m \end{bmatrix}, \begin{bmatrix}K & \kappa^{\top} \\ \kappa & \boldsymbol C \end{bmatrix} \bigg) \]

then \(p(f|\boldsymbol y) = GP(f; \mu_D, K_D)\), where

\[ \begin{aligned} &\mu_D = \mu(x) + \kappa(x)^{\top}\boldsymbol C^{-1}(\boldsymbol y-\boldsymbol m)\\ &K_D(x, x') = K(x,x') - \kappa(x)^{\top}\boldsymbol C^{-1}\kappa(x') \end{aligned} \]

There are multiple forms of covariance functions we can use to describe the correlation between any two support points, e.g. squared-exponential, Matern, periodic, etc.

To decide where we should evaluate next, we need a utility (acquisition) function that balance:

• Exploration: Seek places with high variance
• Exploitation: Seek places with low mean (assume that we are minimizing the function).

Acquisition functions

There are many acquisition functions used in practice. We focus on the expected improvement (EI), the most used acquisition function.

\[ \begin{aligned} &I(x) = \max\{y_{min} - f(x), 0\}\\ &x' = \arg\min_{x \in \mathfrak X}E[I(x)], \end{aligned} \]

We can show that

\[ E(I(x)) = (y_{min} - \hat f(x))\Phi\bigg[\frac{y_{min} - \hat{f}(x)}{\hat{\sigma}(x)}\bigg] + \hat{\sigma}(x)\phi\bigg[\frac{y_{min}-\hat {f}(x)}{\hat{\sigma}(x)}\bigg] \]

How does it work?

(Let’s look at the code)

Some extensions

• The model should account for white noise.
• Consider the scale parameter in the covariance matrix to widen the range.

Some extensions

• The mean of GP is a function with parameters (e.g. linear, quadratic, cubic, etc.).
• Using the full Bayesian approach is time-consuming.
• “Plug-in” approach (MLE of the scale parameter) can turn Gaussian into Student-t. This is not a problem if \(n\) is large enough.

Constrained Optimization

\[ x' = \arg\min_{x \in \mathfrak{X}}f(x)\quad \text{subject to}\quad c(x) \le 0 \]

• The idea is to modify acquisition function to account for only available region.

• Instead of Expected improvement, we use integrated expected conditional improvement.

The conditional improvement is

\[ I(x|x_{n+1}) = \max\{y_{min} - f(x|x_{n+1}), 0\} \]

• \(E(f(x|x_{n+1})|D_n) = \mu_n(x)\) since \(y_{n+1}\) has not come yet.
• \(V(f(x|x_{n+1})|D_n) = \sigma^2_{n+1}(x)\) follows the ordinary GP predictive equation.

We have the expected conditional improvement:

\[ \begin{aligned} \mathbb{E}\bigl[I(x \mid x_{n+1}) \mid D_n\bigr] = \bigl(y_{n_{\min}} - \mu_n(x)\bigr)\, \Phi\!\Bigl(\frac{y_{n_{\min}} - \mu_n(x)}{\sigma_{n+1}(x)}\Bigr) + \sigma_{n+1}(x)\, \phi\!\Bigl(\frac{y_{n_{\min}} - \mu_n(x)}{\sigma_{n+1}(x)}\Bigr). \end{aligned} \]

The integrated expected conditional improvement:

\[ \mathrm{IECI}(x_{n+1}) = -\int_{x\in \mathfrak{X}}\mathrm{E}\{I(x|x_{n+1})|D_n\}w(x)dx \]

• \(w(x)\) plays an important role to control available regions.

Intuition behind IECI

• It does not measure improvement directly at \(x_{n+1}\), as EI does.
• IECI assesses it at a reference point \(x\) under the hypothetical scenario that \(x_{n+1}\) is added into the design.
• If \(x\) still has high improvement after \(x_{n+1}\) has been added in, then \(x_{n+1}\) must not have had much influence on potential for improvement at \(x\).
• If \(x_{n+1}\) is influential at \(x\), then improvement at \(x\) should be small after \(x_{n+1}\) is added in, not large.

Discussion

• Main issues remains in BO
  • What to do with the hyperparameters of the model?
  • How to select points to initialize the model?
  • How to optimize the acquisition function?
• Without constraints, IECI is not superior to EI.
• This method may be extended and improved as we consider white noise.
• We can also consider multi-task and multi-objective BO.
